Japanese Power Cord VCTF 3×1.25mm² 12A 125V with IEC C13 Connector

Custom Length Japanese Power Cable for Electronic Equipment | PSE Application | OEM & ODM Manufacturer

The TISDLIP Japanese 3-Prong Power Cord is designed for electronic equipment requiring a grounded Japanese power connection. It features a Japanese 3-prong plug, IEC C13 connector and VCTF 3×1.25mm² cable, with a standard length of 3000mm and support for customized cable lengths.

The cable uses 50-strand × 0.18mm copper conductors for L/N/E, with a nominal outer diameter of 7.8±0.15mm. The black, white and green conductor configuration provides clear identification of live, neutral and earth conductors.

With 12A 125V rating, RoHS & REACH material requirements and electrical safety testing including 2000V and 4000V AC withstand voltage tests, this power cord is suitable for computers, monitors, printers, audio equipment and other electrical and electronic applications.

TISDLIP provides factory-direct power cord manufacturing with OEM/ODM customization, including cable length, connector configuration, color, packaging and other project requirements.

Detailed Cable Construction

The VCTF cable contains three copper conductors:

The 7.8±0.15mm cable outer diameter is controlled according to the supplied specification, providing a defined cable dimension for subsequent plug and connector assembly.

Applications

This Japanese 3-prong power cord can be used for a wide range of electronic and electrical equipment.

Computers & Monitors

Suitable for compatible desktop computers, monitors and related IT equipment.

Printers & Scanners

The IEC C13 connector makes the cable suitable for compatible office equipment.

Audio Equipment

Can be used for compatible speakers, amplifiers and other audio equipment requiring an IEC C13 connection.

Electronic Equipment

Suitable for various compatible electronic devices and electrical equipment.

Industrial Equipment

For equipment requiring a Japanese 3-prong 125V power connection, subject to the equipment's electrical and safety requirements.

Product Structure

The power cord consists of several major components:

01. Japanese 3-Prong Plug

Provides the input-side connection to a compatible Japanese power outlet.

02. PVC Plug Housing

The molded PVC housing protects the internal plug components and provides mechanical support.

03. VCTF 3×1.25mm² Cable

The three-core cable carries live, neutral and earth connections.

04. Cable Strain Relief

The molded structure at the plug and connector ends helps protect the cable from excessive bending and mechanical stress.

05. IEC C13 Connector

Provides the equipment-side connection for compatible electronic devices.

Manufacturing Process

TISDLIP controls the production process from cable preparation through final electrical inspection.

Cable Preparation

The VCTF 3×1.25mm² cable is cut according to the specified length and processed for assembly.

Conductor Preparation

The copper conductors are stripped and prepared for terminal connection.

Plug Assembly

The conductors are assembled with the Japanese 3-prong plug components.

PVC Injection Molding

PVC material is molded around the relevant assembly to form the required plug and connector structures.

C13 Connector Assembly

The equipment-side IEC C13 connector is assembled according to the required configuration.

Electrical Testing

Finished products undergo electrical inspections according to the product specification, including continuity, polarity and withstand-voltage testing.

Final Inspection

Appearance, cable length, marking, assembly and other specified requirements are checked before packing.

PSE, RoHS & REACH Requirements

According to the supplied technical specification:

• Materials shall meet the latest RoHS & REACH environmental requirements

• Plug, cable and related mechanical/electrical performance shall meet applicable PSE requirements

For projects requiring specific certification documentation, testing reports or compliance documents, the exact requirements can be confirmed according to the destination market and customer's product specification.

Certification and compliance should be confirmed for the exact finished cord configuration rather than assumed from the connector or cable component alone.

Why Choose TISDLIP?

power cords Source Factory

TISDLIP provides factory-direct manufacturing for AC power cords and related power cord components.

Power Cord Manufacturing Experience

Our production capability covers different market-specific power cords, including Japanese, US, UK, EU and other configurations.

Flexible Customization

Cable length, cable specification, connector configuration, color and packaging can be customized according to project requirements.

Component & Finished Cord Supply

Customers can source individual power cord components or complete assembled power cords from the same manufacturing partner.

B2B Bulk Production

We support sample development, specification confirmation and mass production for wholesalers, distributors, equipment manufacturers and brands.

Frequently Asked Questions

What is a Japanese 3-prong power cord?

A Japanese 3-prong power cord is an AC power cable designed for compatible Japanese electrical equipment. This configuration uses a three-prong plug with live, neutral and earth connections.

What cable is used in this Japanese power cord?

The specified cable is VCTF 3×1.25mm², with black, white and green conductors.

What is the rated current and voltage?

The specified rating is 12A 125V AC.

What is the standard cable length?

The drawing specifies 1500±30mm. Custom cable lengths are available.

Can the cable length be customized?

Yes. TISDLIP supports customized power cord lengths according to customer requirements.

What is the conductor construction?

The specification uses 50 strands × 0.18mm copper wire for each conductor.

What is the cable outer diameter?

The specified cable outer diameter is 7.8±0.15mm.

Is the connector an IEC C13 connector?

Yes. The equipment-side connector shown in the product configuration is the IEC C13 / 品字尾 type.

Does this power cord support PSE requirements?

The supplied specification requires the plug, cable and related mechanical/electrical performance to meet applicable PSE requirements. Exact compliance documentation should be confirmed for the finished cord configuration.

Do you provide OEM and ODM services?

Yes. TISDLIP supports OEM/ODM power cord projects, including cable length, cable specification, plug/connector configuration, color and packaging.

B2B Buyer Information

When requesting a quotation, buyers can provide the following information:

1. Plug Type
Japanese 3-Prong

2. Connector Type
IEC C13

3. Cable Specification
VCTF 3×1.25mm²

4. Cable Length
3000mm or customized

5. Rated Requirement
12A 125V

6. Quantity
Sample / Trial Order / Bulk Order

7. Certification Requirement
PSE / RoHS / REACH or other market requirements

8. Packaging
Standard or customized

This allows our engineering and sales teams to quickly confirm the appropriate configuration.
